Aluminium Datasheet
Inspection certificate for aluminum:

Material information: AS-24, Aluminum 5754
AS-24 is made from aluminum alloy 5754, known for its strength, corrosion resistance, and excellent workability. The material is widely used in both industry and design because of its durability and aesthetic quality.
Specifications:
• Alloy: 5754
• Temper: O (Annealed)
• Thickness: 3.0 mm
• Width: 1500 mm
• Surface: Matte aluminum
Mechanical properties:
Tensile strength (Rm): 219 MPa
Yield strength (Rp0.2): 103 MPa
Elongation at break (A50): 25.9 percent
➝ What does this mean?
The material is strong and resistant, which makes it suitable for design and structural applications.
Chemical composition:
Element
Content (percent)
Magnesium (Mg): 2.9
Manganese (Mn): 0.31
Silicon (Si): 0.25
Iron (Fe): 0.32
Copper (Cu): 0.05
Zinc (Zn): 0.04
Titanium (Ti): 0.03
Chromium (Cr): 0.05
➝ Why is this important?
The magnesium content gives the 5754 alloy excellent corrosion and wear resistance, which makes AS-24 ideal for both indoor and outdoor use.
Certifications and standards
AS-24 meets the following standards and quality requirements:
EN 485-1+2+4, EN 515, EN 573-3, EN 15088
ISO 9001 (quality management), ISO 14001 (environmental management), IATF 16949 (automotive industry)
